• Ultra-low noise discrete MIC Preamps with +48V Phantom
Power• Compressors control on first 6 MIC channels• 3-band EQ
with sweepable MID and Peak LEDs on each MIC channels. 4-band EQ and Peak LEDs
on Stereo channels.• Built-in 24-bit DSP effect with 100
presets.• Built-in USB Playback/Record moduleMono ChannelsMic Input:
XLR balancedLine input: 1/4– TRS balancedFreq response: 10Hz ~ 55kHz,
+/- 3dBDistortion (THD=N): <0,03% @ 0dB, 22Hz ~ 22kHz Gain range:
50dBInput sensitivity: -35dBu ~ +15dBuLOW Cut: 75HzSNR <-114dBr Phantom
Power: +48V switchableStereo ChannelsMic Input: XLR balancedLine input:
1/4&ndash; TRS/RCA unbalancedFreq response: 10Hz ~ 55kHz, +/- 3dBDistortion
(THD=N): <0,03% @ 0dB, 22Hz ~ 22kHz Gain range: 50dBInput sensitivity:
-20dBu ~ +20dBuLOW Cut: 100HzSNR <-100dBr Phantom Power: +48V
switchableChannels EQ monoHigh: +/- 15dB @ 12kHz, ShelvingMid: +/- 15dB @
100-8kHz, SweepableLow: +/- 15dB @ 80Hz, ShelvingChannels EQ stereoHigh: +/-
15dB @ 12kHz, ShelvingMid: +/- 15dB @ 3kHzMid: +/- 15dB @ 500HzLow: +/- 15dB @
80Hz, ShelvingImpedancesMicrophone input: 1,8K OhmOther inputs: >10K OhmTape
output: 1K OhmAll other outputs: 120 OhmUSB Record: 1 stereo pair
(switchable between GRP 1-2 and MAIN MIX)Playback: 1 stereo pair (switchable
between Ch 15-16 and MAIN MIX)Power supply: AC 100- 240V 50Hz/60HzPower
consumption: 50 WattMeasurements: 535 x 435 x 85mmWeight: 6,75 Kg
